Reactor tank top emulsifier

Description :

Stainless steel tank top high shear uniform dispersion emulsifier

Top mounted vertical operation: The emulsifying head extends into the tank, and the high-speed rotor (variable frequency speed regulation) generates strong centrifugal force. The material is sucked into the precision gap (0.2-0.5mm) of the fixed rotor in both directions (axial and radial);

Multi gravity field effect: The material is instantly subjected to shear, friction, centrifugal compression, and liquid flow collision in the gap, and the droplets/particles are rapidly torn and refined to the micrometer or even nanometer level;

Turbulent circulation inside the tank: After processing, the material is ejected at high speed through the stator teeth slot, forming three-dimensional turbulence, and repeatedly circulating until reaching the preset particle size (injection grade d90 ≤ 1 μ m, nanoemulsion ≤ 200nm);

Vacuum collaboration: Integrated vacuum system (≤ 10mbar), synchronized removal of bubbles, avoiding oxidation and defects in finished products.

Core parameters: The rotor has a linear velocity of 18-40m/s, generating a linear velocity of at least 15m/s or more at the outer end of the high-speed rotating rotor, which can reach 40m/s, and forming strong mechanical and hydraulic shear, liquid layer friction, and impact tearing. Fully disperse, emulsify, homogenize, crush, and simultaneously inject the material through the stator slot.

Pharmaceutical grade core advantages

Hygiene: The contact materials are all 304/316L stainless steel, with retention design, supporting CIP/SIP online cleaning and sterilization, quick installation connection, and zero obstacles for disassembly and cleaning;

Zero leakage seal: Double end containerized mechanical seal (with cooling/flushing system), resistant to sterilization temperature and pressure (-0.098MPa~1.6MPa), eliminating cross contamination;

Flexible installation: flange type top mounted installation, suitable for various standard storage tanks, can be matched with auxiliary mixing (anchor/paddle), processing viscosity 0-100000mPa · s, universal for water in oil/oil in water systems;

Explosion proof optional: Ex d IIB T4 explosion-proof configuration, suitable for working conditions with organic solvents and flammable materials.

Laboratory R&D: Recommended 0.5-10L models

Pilot scale up: 20-1000L models, equipped with CIP/SIP and vacuum system

Large scale production: above 1000L, combined mixing+vacuum+explosion-proof+automation control

High viscosity materials: choose bottom mounted or anchor type mixing to enhance circulation effect

Stainless steel tank top high shear uniform dispersion emulsifier

Injection series

Injection, nano emulsion, liposome injection, microsphere suspension injection, nano suspension, gel for injection, vaccine injection, etc.

External preparation series

Skin cream, ointment, gel, eye emulsion, suppository, lotion, liniment, wound repair gel, etc.

Oral preparation series

Oral suspension, emulsion, syrup, microcapsule preparation, probiotic dispersion, traditional Chinese medicine extract suspension, etc.

Biopharmaceuticals and formulations

Vaccine adjuvant emulsification, protein peptide dispersion, antibody preparation, cell lysate homogenization, liposome preparation, biological buffer homogenization, etc.

Modern Traditional Chinese Medicine Preparations

Pretreatment of traditional Chinese medicine paste, gel, emulsion, traditional Chinese medicine injection, dispersion of extract, nano treatment of effective ingredients, etc.

This series of equipment is designed and manufactured strictly in accordance with GMP, FDA, and 3A hygiene standards. It has a fully hygienic structure, is easy to clean, and can be cleaned and sterilized online. It is suitable for small-scale research and development, pilot scale production, and industrial scale production in pharmaceutical enterprises. It can be used in conjunction with ingredient tanks, reaction vessels, emulsification tanks, liquid storage tanks, etc., to achieve continuous or batch production under closed, vacuum, and sterile conditions. It is an important equipment for improving drug quality, ensuring batch consistency, and meeting compliance audits.
