Powder liquid homogenization emulsion pump

Description :

Powder suction is extremely fast, uniform, and non layered emulsion pump

The core working unit of the powder suction pump consists of a high-speed rotor stator shear system and a negative pressure suction chamber:

1. Negative pressure powder suction: The motor drives the rotor to rotate at high speed, forming a local vacuum inside the pump chamber. Dry powder, particles and other materials are continuously sucked into the pump through the powder suction port.

2. Liquid powder mixing: The powder enters a high-speed liquid flow and is subjected to strong shear, impact, and turbulence in the gap between the rotor and stator.

3. Dispersion and homogenization: the powder is instantly broken and dispersed into micron sized particles, which are evenly dispersed into the liquid phase to form a stable lotion, suspension or solution.

4. Stable output: The mixed materials are continuously discharged through the discharge port and can directly enter the next process or storage tank.

Pump body design: The interior of the chamber has a smooth transition, no dead corners, and can discharge materials completely to avoid pollution and deterioration.

Modular structure: with fewer vulnerable parts, easy disassembly and assembly, low maintenance costs, and the ability to quickly replace components such as seals and rotors.

Hygiene certification: Complies with strict hygiene standards in the food and pharmaceutical industries, and can provide material certification and cleaning verification plans.

Efficient mixing: The powder is directly sucked into the liquid flow, instantly dispersed, and the mixing uniformity is ≥ 99%, avoiding the problems of traditional stirring and agglomeration.

2. Hygiene and cleanliness: The all stainless steel non retention design allows for online cleaning and sterilization, meeting the high hygiene requirements of the food and pharmaceutical industries.

3. Environmental safety: Fully enclosed powder suction and transportation, no dust leakage, improves workshop environment, and reduces occupational health risks.

4. Convenient operation: It can operate continuously and automatically, with precise control of powder absorption and mixing intensity through frequency conversion speed regulation, and is suitable for multi variety production.

5. Simple maintenance: modular structure, easy disassembly and cleaning, few vulnerable parts, significantly reducing downtime for maintenance.

6. Multifunctionality: It can simultaneously achieve powder transportation, liquid powder mixing, dispersion homogenization, and emulsification, replacing multiple devices and simplifying the process flow.

Powder suction is extremely fast, uniform, and non layered emulsion pump

1. Food and beverage industry

Rapid dissolution and blending of milk powder, protein powder, and whey powder

Homogenization of cocoa powder, coffee powder, fruit powder and liquid mixture

• Dispersion and dissolution of seasonings (salt, sugar, MSG powder) and colloids (pectin, xanthan gum)

• Preparation of sauces, soups, and meal replacement powders

2. Pharmaceutical industry

Preparation of powder suspensions and oral liquid formulations.

Dispersion and emulsification of traditional Chinese medicine extract powder, glucose powder, and medicinal excipients.

Mixing and homogenization of vaccine adjuvants and liposome powders.

Clean workshop powder feeding without dust.

3. Daily chemical industry

Dispersion of cosmetic titanium dioxide, mica powder, and pearl powder.

• Mix of shampoo, bath gel, face cream and other cream lotion.

The addition of powder additives in detergents and cleaning agents.

4. Fine chemical and environmental protection industries

Powder dispersion of pigments, dyes, coatings, and inks.

• Addition and dissolution of water treatment agents (PAC, PAM powder).

Transportation and mixing of lithium battery materials and ceramic powders.

• Addition of sludge conditioner powder.
