Huawei 2288HV5 rack mounted server with dual Intel expandable processors and high-density computing storage

Description :

  The Huawei 2288HV5 is a standard 2U dual rack mounted server designed specifically for high-density computing, virtualization, and distributed storage scenarios in data centers. This model supports the latest generation Intel Xeon scalable processors, providing a powerful computing foundation suitable for enterprise core business systems, cloud computing platforms, and big data processing nodes. As an important member of the Huawei FusionServer Pro series, the 2288HV5 achieves a good balance between performance and energy efficiency, meeting various load requirements from web services to database applications, and helping users build flexible and efficient IT infrastructure.

  The Huawei 2288HV5 adopts a modular design and supports 2 Intel Xeon Scalable series processors, with a maximum TDP of 165W. It is equipped with 16 DDR4 DIMM slots and supports a maximum memory rate of 2933MT/s, with a maximum memory capacity of 2TB. In terms of storage, the front supports 12 3.5-inch or 24 2.5-inch SAS/SATA hard drives, and can be optionally equipped with NVMe SSD, providing local storage capacity of up to 100TB or more. The integrated RAID controller supports levels such as 0/1/5/6/10/50/60 to ensure data security. The whole machine meets the ENERGY STAR certification standard and is equipped with an efficient platinum power module to improve energy efficiency.

  When selecting Huawei 2288HV5, it is necessary to clarify the type of business load. If pursuing ultimate single core performance or high-frequency trading applications, it is recommended to pair it with a high-frequency CPU; If the focus is on virtualization density or in memory databases, priority should be given to configuring large capacity memory. Compared to the 1288H V5 in the same series, the 2288H V5 has more hard drive slots and PCIe expansion slots, making it suitable for storage intensive applications; Compared to 4-way servers, it has a higher cost-effectiveness and is suitable for horizontally expanding clusters. Not suitable for AI training scenarios that require GPU acceleration, it is recommended to choose G-series or heterogeneous computing nodes for such requirements. When purchasing, it is necessary to confirm the depth of the chassis to accommodate the cabinet space.

  When deploying Huawei 2288HV5, it is important to ensure that the front and rear air ducts are unobstructed. It is recommended to isolate the cold and hot channels to improve heat dissipation efficiency. Daily maintenance includes regularly cleaning the dust screen of the air inlet, checking the status of the hard drive indicator lights, and checking the redundancy of the power module. Through the iBMC management chip, remote monitoring, firmware upgrades, and fault diagnosis can be achieved, simplifying the operation and maintenance process. Common faults such as memory errors can be resolved through replacement methods, while hard disk failures require timely replacement and rebuilding of RAID. It is recommended to conduct a comprehensive hardware health check every six months to ensure long-term stable operation, extend equipment lifespan, and reduce overall cost of ownership.
