Galvanized steel sheet common plate flange air duct rectangular ventilation duct for fire smoke exhaust and ventilation engineering
Category:
mechanical equipment/Fans, exhaust equipment/Air duct
Model:
customization
Brand:
Win Run
material:
galvanized steel sheet
shape:
rectangle
connection method:
Common plate flange
Applicable scenarios:
Ventilation/air conditioning/fire smoke exhaust
surface process:
Galvanized anti-corrosion
characteristic:
Good sealing/high strength/easy installation
customized service:
Support customizing specifications according to drawings
Retail Price
9,000,000.00USD
重量
kg
- Product Description
-
material galvanized steel sheet
shape rectangle
connection method Common plate flange
Applicable scenarios Ventilation/air conditioning/fire smoke exhaust
surface process Galvanized anti-corrosion
characteristic Good sealing/high strength/easy installation
customized service Support customizing specifications according to drawings
Description :
This product is a rectangular common plate flange air duct made of high-quality galvanized steel plate, widely used in modern building ventilation, air conditioning, and fire smoke exhaust systems. From the picture, it can be seen that the surface of the air duct presents a unique zinc flower texture of the galvanized layer, which has good corrosion resistance and durability, and can effectively adapt to damp or complex installation environments, extending its service life.
The two ends of the air duct are connected using advanced common plate flange (TDF) connection technology. The flange is integrated with the air duct body and reinforced with bite and corner brackets, resulting in high structural strength and superior sealing performance. This design not only ensures the stability of the pipeline system under high-pressure air supply or exhaust conditions, preventing air leakage, but also greatly simplifies the on-site installation process, improves construction efficiency, and reduces labor costs. The inner wall of the air duct is smooth and flat, with good aerodynamic performance, which can effectively reduce airflow resistance, reduce operating noise, and ensure efficient and quiet operation of the ventilation system.
This product is suitable for various large-scale commercial complexes, office buildings, hotels, hospitals, underground garages, factory workshops, and civil defense projects. Whether used for daily fresh air exchange, central air conditioning supply and return air, or as an emergency fire smoke exhaust channel, it can provide reliable solutions. Supporting non-standard customization based on engineering drawings, it can produce air ducts and accessories of different specifications and sizes (such as long side, short side size, and plate thickness) to meet diverse engineering design needs. It is an ideal choice for HVAC engineering contractors and building materials purchasers.
