JOSEF intermediate relay XJZJ-201XMT AC220V

Description :

　　purpose

　　This series of intermediate relays is used in various protection and automatic control devices to increase the contact capacity between protection and control circuits

　　Technical Specifications

　　Main performance

　　The wires used in conventional 100V and 220V electromagnetic small room relays are very thin and have a large number of wires, resulting in easy breakage, low reliability, long action time and return time, and other disadvantages.

　　This series of intermediate relays uses a static sub control circuit to control multiple sealed inlet compartments to conduct or disconnect simultaneously. It has the following performance and characteristics: 1. It adopts high-performance sealed electrical appliances, moisture-proof, dustproof, continuous wiring, and high reliability.

　　2. Accurate operating voltage, high return coefficient, no jitter, low power consumption, multiple contacts operating or returning simultaneously (100% controllability).

　　3. After the relay is activated, there is a light indication and a small power indicator.

　　4. The electrical and mechanical lifespan of electrical appliances is long.

　　5. High insulation withstand voltage level, large contact capacity, and low contact resistance.

　　6. Good anti-interference characteristics, suitable for places with strong interference or poor power supply voltage quality.

　　Intermediate relay XJZY-220 DC220V cabinet bottom plate fixed installation

　　Static intermediate relay XJZY-31 DC220V board front wiring

　　Intermediate relay XJZY-39C 110VDC board rear wiring

　　Intermediate relay XJZY-204 DC220V

　　Static intermediate relay XJZY-317C DC220V

　　Intermediate relay XJZY-33A

　　The starting voltage of intermediate relay XJZY-204XMT shall not be less than 70% of the rated voltage

　　Static intermediate relay XJZJ-31 AC220V

　　Intermediate relay XJZJ-15 AC220V

　　Intermediate relay XJZJ-220 AC220V board rear wiring

　　Jump in position power monitoring relay XJZJ-201XMT AC220V

　　Static intermediate relay XJZJ-208 voltage 380V board front wiring with base

　　Intermediate relay XJZJ-204 AC220V

　　Static adjustable delay intermediate relay XJZS-244
